E3276s-920

Huawei E3276 150Mbps Cat 4 LTE Surfstick

Huawei E3276 4G LTE Cat4 150Mbps USB Modem is the World's first LTE Cat4 Stick, and allows speeds of over 100 Mbit/s download - precisely 150 MBit/s on LTE FDD network. The FDD-LTE modem operates on the 800/900/1800/2100/2600MHz band with GSM and UMTS backward. The UMTS network can achieve up to 84 Mbps download speed due to DC-HSPA+ technology. There are many variants for HUAWEI E3276 Cat 4 LTE Surfstick, such as HUAWEI E3276s-150, HUAWEI E3276s-151, HUAWEI E3276s-152, HUAWEI E3276s-210, HUAWEI E3276s-500, HUAWEI E3276s-601 and HUAWEI E3276s-920 etc..

Below is the 4G LTE Sprctrum & Frequency bands that HUAWEI E3276 could support by its variants:

HUAWEI E3276s-152:

* 4G LTE FDD 800/2600MHz

* 3G UMTS 900/1900/2100MHz

* GSM 850/900/1800/1900MHz

HUAWEI E3276s-151:

* 4G LTE FDD (DD800/1700/1800/2600MHz)

* 3G UMTS 900/1900/2100MHz

* GSM 850/900/1800/1900MHz

Huawei E3276s-150(Vodafone K5007 and Megafon M150-1):

* 4G LTE Band 1/3/7/8/20 FDD (DD800/900/1800/2100/2600MHz)

* 3G UMTS 900/AWS/1900/2100MHz

* GSM 850/900/1800/1900MHz

HUAWEI E3276s-861:

* 4G LTE Band 7/38/39/40 (FDD 2600MHz TDD 1900/2300/2600MHz)

* 3G UMTS 900/2100MHz  & TD-SCDMA 1900/2100MHz

* GSM 850/900/1800/1900MHz

HUAWEI E3276s-210:  Band 3/7/20/38 (FDD 800/1800/2600 TDD 2600MHz)

Huawei E3276s-601:  Band 3/7/40 (FDD 1800/2600MHz & TDD 2300MHz)

Huawei E3276s-920:

* 4G Band 38/40 (TDD 2300/2600MHz)

* 3G UMTS/HSPA+ 900/2100MHz

* GSM 850/900/1800/1900MHz

HUAWEI E3276s-500:

* Band 2/4/5/7  FDD 1900/AWS(1700/2100)/850/2600Mhz

* 3G DC-HSPA+ 850/1900/2100MHz

* GSM 850/900/1800/1900MHz

HUAWEI E3276s-505:

* 4G Band 1/2/4/5/12/17 (FDD 2100/1900/AWS(1700/2100)/850/700MHz)

* 3G 850/AWS/1900/2100 Mhz

* GSM 850/900/1800/1900MHz

Huawei E3276s-862:

* 4G Band 1/7/35/40/41/38 (FDD 2100/2600MHz, TDD 1900/2300/2500/2600Mhz)

* 3G WCDMA 2100 Mhz

* GSM 850/900/1800/1900MHz

Huawei E3276 4G USB Stick has the Plug & Access function, which means you can plug in the stick and just start surfing, no drivers needed. Per the test from HUAWEI, the connection time is within 15 seconds.

Network bands:

* LTE FDD: 800/900/1800/2100/2600 Mhz

* UMTS: 2100/AWS/900/1900

* GSM: 850/900/1800/1900

* LTE Cat4 DL at up to 150Mbps

* LTE UL up to 50Mbps

* External Antenna Interface, Receive Diversity

* USB 2.0 High Speed

* SIM/USIM card: standard 6-pin SIM card interface

* Micro SD Card Slot

* Dimensions: 92mm x 32mm x 14mm

* Weight: 30g

* OS: Windows XP/Vista/7, Linux, Mac OS.
