  • Product Name:

    Huawei ME909u-523 ME909u-523D Mini PCIe LTE Module
  • Model No:

    ME909u-523
  • Unit Price:

    $29/piece
  • Mimimum Order Quantity:

    1
  • Payment Term:

    T/T,Westunion,Paypal,Moneygram
  • Delivery Lead Time:

    3 Days after Payment
  • Place Of Origin:

    China
Contact Now
Detailed Product Description

Huawei ME909u-523 (ME909u-523D) PCIe module Technical Specifications:



* LTE Cat3 PCIe module



* Support 4G LTE (FDD) B2/B4/B5/B17



* LTE FDD: DL 100 Mbps/UL 50 Mbps @20M BW cat3



* Support 3G DC-HSPA+/HSPA+/HSPA/WCDMA B2/B4/B5



* DC-HSPA+: DL 43.2 Mbps/UL 5.76 Mbps



* HSPA+: DL 21.6 Mbps/UL 5.76 Mbps



* LTE DL 2*2 MIMO and HSPA+/DC-HSPA+ DL 2*2 MIMO



* Power supply: 3.0 V to 3.6V (typical: 3.3V)



* Voice Features: DTMF, PCM Voice



* SMS features: MO/MT Text PDU mode



* Additional Features

- CDC-ECM

- GNSS: Standalone, A-GPS, GPS XTRA, Glonass

- FOTA

- Firmware Update via USB

- Sleep mode



* Interfaces:

- Mini PCIe interface

- Antenna interface

- USB 2.0 High speed

- PCM Voice

- SIM Card

- LED

- Power supply

- Reset



* Temperature range

- Operational: -20° C to 60° C

- Extended: -30° C to 70° C



* AT commands

- 3GPP TS 27.007 and 27.005

- Huawei extended AT command



* OS: Linux, Android



* Approvals & Certifications: FCC, RoHS & WEEE Compliant, AT&T



* Dimensions: 51 mm x 30.4 mm x 3.4 mm



* Weight: approx. 12g
