Wireless Airprime MC7305 lte4gmodule

Sierra AirPrime MC7305 is the new4Gmodule from Sierra Wireless that support4GLTE Band1/3/7/8/20. The4Gmodule MC7305 provides LTE, DC-HSPA+, HSPA+, HSDPA, HSUPA, WCDMA, GSM, GPRS, EDGE, and GNSS connectivity for notebook, ultrabook, and tablet computers over several radio frequency bands. The device also supports2G/3Groaming, subject to carrier provisioning.

AirPrime MC7305 module allows developers to take advantage of the latest generation of high-speed mobile networks, delivering up to 100Mbps download speeds and 50Mbps upload speeds over LTE with fall-back to all3G/HSPA+ networks. The module includes enhanced location capabilities using A-GPS, GPS Xtra, and Glonass. It also provides support for Linux and Windows 7 and Windows 8. The MC7305 module has been optimized for low power consumption, enabling longer battery life in applications.

Sierra AirPrime MC7305 Technical Specificationis:

* Model No: MC7305

* Category:4GModule

* Manufacturer: Sierra Wireless

* Chipset: MDM 9215 Qualcomm

* Form Factor: PCIe M.2

* Pins: 52-pin

* Technologies: LTE,HSPA+,UMTS,GPRS(Class 12),GSM,EDGE,HSDPA

* Frequency bands

- LTE: 2600/1800/2100/900/800 MHz

- WCDMA: 850/900/1900/2100 MHz

- GPRS/EDGE: 850/900/1800/1900 MHz

- GPS: 1575.42MHz

- GLONASS: 1602MHz

* Data rates:

- Downlink 100Mbps (20MHz bandwidth), 50mbps (10MHz bandwidth)

- uplink 50Mbps (20MHz bandwidth), 25mbps (10MHz bandwidth)

* MIMO Support

* Temperature: -25 o C to 60 o C

* Certifications: CE, GCF, NCC (Taiwan)

* Carriers Approved: Vodafone, Telstra

* Interfaces: USB

* Voice Support: None

* GPS Support: Yes

* Dimensions: 51 x 30 x2.75 mm
