Hua Wei MU736 HSPA+ module

  • Product Name:

    MU736 HSPA+ module NGFF interface GPS module

  • Model No:

    MU736

  • Unit Price:

    USD69

  • Mimimum Order Quantity:

    1picese

  • Payment Term:

    T/T, Western Union, MoneyGram, PAYPAL

  • Delivery Lead Time:

    3-7days after payment

  • Place Of Origin:

    shenzhen
Contact Now
Share
Detailed Product Description

  MU736 HSPA+ module NGFF interface GPS module

Product Description

The MU736 is a HSPA+ module with NGFF interface, supporting Penta-band (B1/B2/B4/B5/B8) for worldwide network coverage, low power consumption, GPS, enabling easier and more flexible design and integration into end devices. In addition, the MU736 supports all NGFF features to optimize performance, power consumption, and usability.MU736 is an ideal choice for PC OEMs and ODMs to use in long battery life, thin form factor devices such as Ultrabooks and tablets requiring best in class cellular platform KPIs (e.g. performance, size, and current consumption).

  • Form Factor

M.2

  • Bands

Penta-band WCDMA/HSPA/HSPA+ : 2100/1900/900/850/AWS MHz

Quad-band EDGE/ GPRS/GSM: 1900/1800/900/850 MHz

  • Data Transfer Rate

WCDMA PS: UL (384 kbps) / DL (384 kbps)

UL/DL HSPA: UL (5.76 Mbps)/ DL (7.2 Mbps)

UL/DL HSPA+: UL (5.76 Mbps)/ DL (21Mbps)

GPRS/EDGE: Multi-slot Class 33, Class B

  • Interface

Antenna interfaces x 2

M.2 Socket 2

USB 2.0 interface high speed

Power supply

UICC interface

  • Power Supply

Supply voltage range: 3.135V~4.4V (3.3 V recommended)

  • Voice

/

  • Temp Range

Normal operation: - 10°C to +55°C

Extended operation: -20°C to +70°C

Storage: -40°C to +85°C

  • GPS/Glonass

GPS Standalone, A-GPS

  • Special Features

SIM Hotswap

BodySAR

Ultrabook feature support (ACT, WiFi Offload , DPTF)

Tunable Antenna

Supporting MO and MT

Supporting formats of PDU

Point-to-point and cell broadcast

  • Operating System

Windows 7 / Windows 8 / Android 4.0 or above
